Diagnostic instruments
Pediatric Laryngoscope Set
Also called Child laryngoscope set · Infant laryngoscope set
A fiber-optic laryngoscope set of four curved blades in the pediatric sizes 00, 0, 1 and 2, with one battery handle, in a fitted case.
The battery is added by the buyer. Tahir Group of Industries does not make, supply or source batteries.
CE marking under manufacturer self-declaration for Class I, non-sterile, non-powered instruments under Regulation (EU) 2017/745 (MDR). This is not a Notified Body certificate, and the issuer, CNC Services, is not a Notified Body.
What it is
A complete laryngoscope set for children, supplied as one boxed item: four curved blades in sizes 00, 0, 1 and 2 and one battery handle, seated in a fitted case. A laryngoscope holds the tongue aside and lifts the epiglottis so the larynx can be seen directly while a tube is passed. The size range starts at 00, which is smaller than the smallest blade in the adult sets. Light reaches the blade tip through fiber optics, so the lamp is out of the viewing path. The battery is not supplied.
Pediatric anesthetists, neonatal and pediatric intensive-care staff, emergency-medicine physicians and paramedics.
Full specification
- Category
- Diagnostic instruments
- Sizes and patterns
- Size 00 · Size 0 · Size 1 · Size 2
- Steel lines
- Economy line: AISI 410 · Clinical line: AISI 420 · Premium line: AISI 420-440C · Executive line: AISI 440C
- Minimum order
- 150 sets
- Mixing sizes
- Whether one minimum may be spread across sizes and patterns is agreed per order.
- Lead time
- Instruments ~2-3 weeks · full sets ~4-6 weeks after advance.
- Supplied
- Non-sterile
- Set includes
- 4 - Curved blades, sizes 00, 0, 1 and 2 · 1 - Battery handle · 1 - Fitted carry case
- Also known as
- Child laryngoscope set · Infant laryngoscope set
What it does
- Four curved blades in sizes 00, 0, 1 and 2, the pediatric range.
- Size 00 is smaller than the smallest blade offered in the adult sets.
- One battery handle takes every blade in the set through a common hook-on fitting.
- Fiber optics carry the light to the blade tip, keeping the lamp out of the line of sight.
Steel & finish: you choose the line
How the four tiers differOne-year guarantee on Premium and Executive tier instruments, hollowware and sterilization containers: any technical manufacturing defect, including material faults and rust, is replaced free of charge. Damage from handling or accidents is not covered.
Questions importers ask
- What is the minimum order for Pediatric Laryngoscope Set?
- 150 sets. Whether one minimum may be spread across sizes and patterns is agreed per order.
- Which sizes and patterns of Pediatric Laryngoscope Set do you make?
- Size 00; Size 0; Size 1; Size 2.
- Can I get a sample of Pediatric Laryngoscope Set before a bulk order?
- Free samples for all buyers: you pay only the sample shipping cost. Samples dispatched within 48 hours.
- How long does an order take?
- Instruments ~2-3 weeks · full sets ~4-6 weeks after advance.
- Can Pediatric Laryngoscope Set carry my own brand?
- Instruments are marked to the buyer's requirement (TGI, unmarked, or the buyer's own brand), agreed on the order. How the manufacturer is named on your label is agreed per order.
Buying for the United States? Terms for US importers and distributors.
Material and quality
| Line | Steel | Origin | Finish | Inspection |
|---|---|---|---|---|
| Economy line | AISI 410 | Pakistani or Taiwanese | satin, passivated | sample: visual + dimensional |
| Clinical line | AISI 420 | Pakistani or German | satin, passivated | sample + boil test |
| Premium line | AISI 420-440C | German or Japanese | fine polish, passivated | tighter sample + hardness test |
| Executive line | AISI 440C | German or Japanese | mirror polish, passivated | 100% inspection + laser mark |
This is the steel each line is made from as standard. A different origin can be supplied on request (a lower grade in Japanese steel, for example), agreed on your order.
Premium is the line where the choice is yours: 420 or 440C, agreed on your order. Economy is always 410 and Executive is always 440C. Those three are the instrument steels. Hollowware and sterilization containers are made in AISI 202 on a Clinical order and AISI 304 on a Premium or Executive one, and they are not offered in the Economy line at all, which is the section above.
True of every order
Instruments are marked to the buyer's requirement (TGI, unmarked, or the buyer's own brand), agreed on the order.
Customized packaging is part of what TGI supplies. Your own printed boxes, your labels, your brand on the pack, or plain export packing, whichever your market needs. The packing for your order is agreed with you and confirmed on the order.
Manufactured under the quality management system covered by TGI's ISO 9001:2015 and ISO 13485:2016 certificates. Certificate numbers and the issuer's registry are on the certification page. Open the certificates
Every batch of steel is ordered to a specified grade and arrives with the mill's own certificate, which identifies the mill and states the grade. TGI checks the material at the factory against its own requirement before it goes into production. That check is TGI's own inspection, not an independent laboratory test.
TGI manufactures in its own factory in Sialkot and also supplies articles made by contracted partner workshops, to TGI's specification. Which applies to a given article is confirmed on your order.
One-year guarantee on Premium and Executive tier instruments, hollowware and sterilization containers: any technical manufacturing defect, including material faults and rust, is replaced free of charge. Damage from handling or accidents is not covered. The year runs from the day the goods leave Sialkot.
If something is wrong with a delivery (a manufacturing defect, or a short or wrong article), tell us on WhatsApp within 7 days of delivery, with a video and photographs of what arrived. Replacement instruments are sent free of charge and dispatched within 24 hours of us seeing them; you pay the shipping, and they reach you as a normal order does.
Damage that happened after the goods left Sialkot is a claim against your carrier. The video of your parcel at the shipping office is sent to you before shipment and is the evidence that claim needs.
Next step
Ask for a quote on Pediatric Laryngoscope Set.
Tell us the tier and the quantity, and we answer with a written offer. Free samples for all buyers: you pay only the sample shipping cost. Samples dispatched within 48 hours.
- Payment
- Payment by TT bank transfer. Structures: 50/50, 70/30, or 100% advance, agreed per order. Balance always before shipment, released against video proof of your finished parcel at the shipping office.
- Freight
- Base price FCA Sialkot: TGI hands the goods and the export documents to your carrier or your own agent at the factory, and your tracking starts there. For a sea container the basis is FOB Karachi. The buyer pays freight: ship on your own carrier account or your own forwarder, or have delivery arranged through TGI's logistics partner and quoted per destination.
