Surgical instruments
Castroviejo Forceps TC Straight
Web referenceTGI-C-C029472CQuote this to us. It identifies this page, not a factory part number.
Sizes TGI publishes24cm · 18cm · 14cm Printed on TGI's own catalogue photograph of this article.
Also printed on the photographTC · Straight Printed on TGI's own catalogue photograph of this article.
Also called Eye forceps
The jaw tips carry tungsten-carbide inserts machined into a fine cross-hatched tying platform, rather than plain steel tips, built to hold a suture thread without it slipping during knot-tying.
Ophthalmic forceps are a family of small, fine-tipped forceps for handling tissue and suture in and around the eye, with overall lengths mostly between 75 and 120 mm and jaw contact measured in fractions of a millimeter. Two working families make up most of the catalog: colibri-type or corneal utility forceps, whose tips meet at a fine point with teeth from about 0.10 to 0.50 mm for holding corneal or conjunctival tissue, and tying forceps, whose tip carries a flat platform a few millimeters wide for gripping a suture without cutting it. Tips are set straight or angled, commonly at 45°, to the shaft. Handles are spring-action (the arms open on their own spring and are squeezed shut), rather than ring-and-lock, since the instrument is worked with a light pinch rather than a full grip.
Minimum order300 instrumentsThe minimum for surgical instruments. Mixed orders are quoted against your list.
Lead timeInstruments ~2-3 weeks · full sets ~4-6 weeks after advance.
Quality control
The inspection step is set by the line you order.
- Economy line
- sample: visual + dimensional
- Clinical line
- sample + boil test
- Premium line
- tighter sample + hardness test
- Executive line
- 100% inspection + laser mark
Finish A color is a second choice, made on top of the line. Colored finishes on request, on any instrument, in addition to the steel line. Evidenced: black · gold · rose gold · blue · rainbow (anodised titanium).
How it is built
- Spring-action handle (jaws open on their own spring; no ring or lock)
- Colibri / corneal utility tip: fine point, teeth from about 0.10 mm to 0.50 mm
- Tying-forceps tip: flat platform, roughly 0.5 mm to 7 mm wide, for gripping suture without cutting it
- Tip set straight or angled (commonly 45°) to the shaft
- Overall lengths mostly in the 75-120 mm (3-4 3/4 in) range across the family
- Stainless steel, some patterns titanium
- Straight and curved shaft forms both made
PatternsColibri / corneal utility forceps · Pierse-type · Troutman-Barraquer · University of Kansas · Maumenee · Shepard (tying) · McPherson (tying) · Jaffe (tying) · Sinskey (tying) · O'Gawa (tying) · Harms-Tubingen (tying)
The standard sizes this kind of instrument is made in
Pierse-type colibri forceps, 80 mm (3 1/8 in), 0.1 mm or 0.3 mm teeth · Troutman-Barraquer corneal utility (colibri type), 75 mm (3 in), 0.12 mm teeth · University of Kansas corneal forceps: 105 mm (4 1/8 in), 2x2 teeth angled 45°, 7.0 mm tying platform · Colibri-type corneal utility forceps, 105 mm (4 1/8 in), 0.12 mm teeth angled 45°, 6.0 mm tying platform · Maumenee corneal forceps, 120 mm (4 3/4 in), 0.5 mm tying platform, 0.10 mm teeth, angled 45° or 90° · McPherson tying forceps, 80 mm (3 1/8 in), 4.0 mm smooth platform · Shepard tying forceps, 108 mm (4 1/4 in), 4.0 mm platform · Jaffe tying forceps, 102 mm (4 in), smooth jaws · Sinskey tying forceps, 110 mm (4 1/4 in), 7.0 mm platform · O'Gawa tying forceps, 110 mm (4 1/2 in), 0.5 mm smooth platform · Harms-Tubingen tying forceps, 105 mm (4 1/8 in)
These are the sizes the pattern is manufactured in across the trade. They are not a stock list. Tell us the size you need and we will quote against it.
This describes the ophthalmic forceps as an article. 5 other articles in this catalog share it: the sentence above is what separates this one. This describes the article. The steel, the finish and the inspection step are set by the line you order.
Other versions
The same instrument in another figure, finish, size, color or case, each at its own address with its photograph.
Material and quality
| Line | Steel | Origin | Finish | Inspection |
|---|---|---|---|---|
| Economy line | AISI 410 | Pakistani or Taiwanese | satin, passivated | sample: visual + dimensional |
| Clinical line | AISI 420 | Pakistani or German | satin, passivated | sample + boil test |
| Premium line | AISI 420-440C | German or Japanese | fine polish, passivated | tighter sample + hardness test |
| Executive line | AISI 440C | German or Japanese | mirror polish, passivated | 100% inspection + laser mark |
This is the steel each line is made from as standard. A different origin can be supplied on request (a lower grade in Japanese steel, for example), agreed on your order.
Premium is the line where the choice is yours: 420 or 440C, agreed on your order. Economy is always 410 and Executive is always 440C. Those three are the instrument steels. Hollowware and sterilization containers are made in AISI 202 on a Clinical order and AISI 304 on a Premium or Executive one, and they are not offered in the Economy line at all, which is the section above.
True of every order
Instruments are marked to the buyer's requirement (TGI, unmarked, or the buyer's own brand), agreed on the order.
Customized packaging is part of what TGI supplies. Your own printed boxes, your labels, your brand on the pack, or plain export packing, whichever your market needs. The packing for your order is agreed with you and confirmed on the order.
Manufactured under the quality management system covered by TGI's ISO 9001:2015 and ISO 13485:2016 certificates. Certificate numbers and the issuer's registry are on the certification page. Open the certificates
Every batch of steel is ordered to a specified grade and arrives with the mill's own certificate, which identifies the mill and states the grade. TGI checks the material at the factory against its own requirement before it goes into production. That check is TGI's own inspection, not an independent laboratory test.
TGI manufactures in its own factory in Sialkot and also supplies articles made by contracted partner workshops, to TGI's specification. Which applies to a given article is confirmed on your order.
One-year guarantee on Premium and Executive tier instruments, hollowware and sterilization containers: any technical manufacturing defect, including material faults and rust, is replaced free of charge. Damage from handling or accidents is not covered. The year runs from the day the goods leave Sialkot.
If something is wrong with a delivery (a manufacturing defect, or a short or wrong article), tell us on WhatsApp within 7 days of delivery, with a video and photographs of what arrived. Replacement instruments are sent free of charge and dispatched within 24 hours of us seeing them; you pay the shipping, and they reach you as a normal order does.
Damage that happened after the goods left Sialkot is a claim against your carrier. The video of your parcel at the shipping office is sent to you before shipment and is the evidence that claim needs.
